Angle Milling Fixtures

Scope and process

Engineering workflow for angle milling fixtures at Dahegam, Gandhinagar, Gujarat, India: 3D CAD modeling of part workholding envelope → FEA clamping force and deflection analysis → CNC machining of hardened baseplates and locator nests → grinding of locating dowels and wear pads → laser CMM verification of critical datum points.

Materials we work with

Angle plate body machined and ground to the set angle, dowelled and bolted so cutting forces cannot creep it.

Tooling support

Locates the part on datum faces and holds it at the set angle to the table.

Choosing the right option

When requesting a proposal for angle milling fixtures, please provide component 3D CAD models (STEP/IGES), 2D part drawings indicating critical datums, machine table specifications (T-slot pitch, pallet size), and target cycle time. Quotes with 3D concept layouts are issued within 24 hours.

Quality checks and inspection

On a fixture the check that matters is the set angle against a sine bar, and repeatability after a clamp cycle. Dimensions are verified on CMM against the fixture drawing before despatch.

Commissioning and handover

Proved by machining a first-off at the set angle and checking it against a sine bar, not by measuring the fixture alone.

Export packing and lead time

Ships assembled with locating elements fitted and clamp positions set. HEMSUN is a DGFT IEC registered exporter (Government of India); commercial invoice, packing list and certificate of origin accompany international despatch.

Maintenance and spare parts

The angle drifts if dowels work loose under cut. Recheck the set angle periodically rather than assuming it is fixed.
